Combustion system
Dismantle the combustion
chamber sealing cover
following the basic
dismantling method.
Combustion system dismounting
Time: 5 min
1.
Combustion system dismounting
2.
Dismantle the 4 screws
of maintain cover on top,
and take out the maintain
cover.
Dismantle the 2
installation screws ame
testing needle or ignition
needle as shown above,
then take out the ame
testing needle or ignition
needle manually.
Unscrew the Heating
temperature sensor by 15
mm spanner and take it
out.
Tools:
Tools:
