ROC COMBI HE 2802 - Fan

49
Dismantle the combustion
chamber sealing cover
following the basic
dismantling method.
Fan dismantling
Time: 8 min
1.
Fan dismantling
2.
Dismantle the 4 nuts
connected with fan by
8mm spanner, and then
dismantle the connected
gas pipe by 24mm
spanner.
Unscrew the Heating
temperature sensor by
15 mm spanner and take
it out.
Take out the silencer after
dismantled the 3 screws
connected with it.
Take out the whole fan
and silencer.
Tools:
Tools:
Fan
