51
Heat exchanger dismounting
3.
Heat exchanger dismounting
4.
Unscrew the 2 heating inlet
water pipe connection nuts
by 30mm spanner; take
heating inlet water pipe out.
Dial-out the pipe clip, and
unscrew the nut on ‘A’,
and take out the siphon
pipe.
Dismantled the 2 screws
on the bottom of siphon
pipe.
Dismantled the 4 screws
on the smoke pipe outlet
by screwdriver and take
out the outlet ange.
Tools:
Tools:
Unscrew the 2 heating
outlet water pipe
connection nuts by
30mm spanner; take
heating outlet water pipe
out.
Take out the inside
smoke pipe connection
pipe upwardly.
