7 Block codes for extended host interface
Roche Diagnostics
COBAS INTEGRA 400 plus analyzer/Cedex Bio HT Analyzer · Software version 3.6/5.1 · Host Interface Manual · Version 1.24
Block codes for extended host interface 131
Cassette status blocks
In this section
Block 50: Cassette status request (131)
Block 55: Cassette Status Response (131)
Block 59: Failed Cassette Status Request (131)
Block 50: Cassette status request
Block 50 is used to interrogate the cassette status. Block
50 has no lines.
Block 55: Cassette Status Response
This request provides the status for all cassettes on
board.
Block 59: Failed Cassette Status Request
Block 59 contains Line 96 and provides the eventual error
encountered following request with Block 50.
Line code Description Iteration
(1)
(1) m is the total number of cassettes on board. The maximum number
is 32.
36 Cassette definition
1 to m
37 Tests left
39 Cassette Status
49 Rack Position
y Block 55
Line code Description
96 Error Message
y Block 59
