Need help? Call 1-800-6
20-2790 (U.S. and Canada)
RF-HTLF23
2
Use the hex key (
14
) to secure the arm assembly to the wall plate (
08
) with the
wall plate screws (
13
).
CA
UTION
: These wall plate screws must be installed to secure your TV onto the wall
plate assembly
.
13
14
11
08
20
22
