RocketFish RF-HTLF23 - Step 3: Attach Horizontal Brackets

10
Need help? Call 1-800-620-2790 (U.S. and Canada)
STEP 3 - Option 1: Attaching the horizontal brackets to a
TV with a flat back
CAUTION: To avoid personal injury or property damage, do not use power tools.
1 Align the holes you noted on the horizontal brackets (04) with the screw holes
on the back of your TV.
2 Place the washers (
02) over the holes in the brackets that align with the screw
holes on the back of your TV, then insert the screws that you selected in
STEP 2 (
01) through the washers. Make sure that the brackets are level.
3 Tighten the screws until they are snug against the brackets. Do not over tighten.
You’ll need
4
2
1
02
Washer
(4)
01 Screws (4)
OR
04 Horizontal
brackets (2)
OR
OR OR
Phillips screwdriver
Level
