3
Need help? Call 1-800-6
20-2790 (U.S. and Canada)
RF-HTLF23
Specifications
•
Maximum
T
V weight: 100 lbs. (45.3 kg)
•
Screen size: Fr
om 40 in. to 75 in. (
101.6 cm to 190.5
cm) diagonal
•
Overall dimensions (H ×
W
): 17.7 × 25.1 in. (45 cm × 63.9
cm)
•
W
al
l-mount weight:
18.8 lbs. (8.5 kg)
•
F
or customer ser
vice, call: 1
-800-620-27
90
Dimensions
25.14"
(63.9 cm)
17.72"
(45 cm)
2
4
Table of Contents
Table of Contents
2
Introduction
2
Important Safety Instructions
2
Specifications
3
Dimensions
3
Tools Needed
4
Package Contents
5
TV Hardware
6
Concrete Installation Kit CMK1
7
Installation Instructions
7
Select Screws, Washers, and Spacers
9
Attaching the Horizontal Brackets to a TV with a Flat Back
10
Attaching the Vertical Bracket
12
Determine Wall-Mount Location
13
Installing on a Wood Stud Wall
14
Installing on a Solid Concrete or Concrete Block Wall
17
Attach the Arm Assembly to the Wall Plate
20
Attach Your TV to the Arm Assembly
22
Managing Cables
24
Adjust Tilt
24
Removing Your TV from the Wall Mount
25
Adjust the Level
25
Lifetime Limited Warranty
26
