12
Need help? Call 1-800-620-2790 (U.S. and Canada)
STEP 4 - Attaching the vertical bracket
CAUTION: To avoid personal injury or property damage, do not use power tools.
1 Lay the vertical bracket (05) on top of the horizontal brackets (04). Make sure
that the bracket is centered.
2 Secure the vertical bracket to the horizontal brackets with the TV interface
screws (
06). Tighten the screws until they are snug against the vertical brackets.
Do not over tighten.
You’ll need
06 TV interface
screw (4)
Phillips screwdriver
05 Vertical bracket (1)
