24
Need help? Call 1-800-620-2790 (U.S. and Canada)
STEP 9 - Managing cables
• Fully extend the arm assembly (11) to provide enough slack, then routing
cables along the arms and inserting them into the channels on the arms to
provide a clean look to your installation.
STEP 10 - Adjust tilt
Note: After your TV is in place, tighten the tilt tension knob to prevent unwanted
movement.
• Loosen the tension knob with your fingers or the hex key (14), adjust the tilt
angle, then tighten the knob to keep your TV in place.
