7
RF-HTMF19
TV Hardware
Lbl. Hardware # Lbl. Hardware #
01
4
02
4
4
03
4
4
4
06
4
09
2
10
2
11
1
M4 × 12 mm screw
M4 washer
M4 × 35 mm screw
M6/M8 washer
M6 × 12 mm screw
Spacer (2.5 mm)
Spacer (5 mm)
M6 × 35 mm screw
Spacer (22 mm)
M8 × 16 mm
screw
TV bracket screw
M5 × 8.5 mm
M8 × 25 mm
screw
Lag screw 5/16 × 2 3/4 in.
M8 × 35 mm screw
Washer 5/16 in.
M8 × 50 mm screw
Locking screw
M5 x 6 mm
