Rockwell Automation Publication 842E-UM002A-EN-P - November 2013 61
Appendix C
Faults and Alarms Dialog Box
The Faults and Alarms dialog box displays the current status of faults and
alarms in the controller for an axis. The display is read-only except for the
ability to clear logs. Fault and alarm entries are displayed only when you
are online with a controller. See also Chapter 6, “Diagnostics and
Troubleshooting.”
Quick View pane
The Quick View pane gives you a quick summary of faults and alarms
related to the axis you select in the Controller Organizer. The information
includes the type of axis, description, axis state, faults and alarms.
