36 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020D-EN-P - October 2008
Specifications
1769-L32E, 1769-L35E - Technical Specifications
Attribute 1769-L32E 1769-L35E
Communication ports Channel 0
Isolated RS-232
38.4 Kbaud max
EtherNet/IP
10/100 BASE-T
User memory 750 KB 1.5 MB
Nonvolatile memory 1784-CF64 or 1784-CF128 CompactFlash card
Number of I/O modules,
max
16 I/O modules 30 I/O modules
Number of I/O banks, max 3 banks
Backplane current 660 mA at 5V DC
90 mA at 25 V DC
Power consumption 5.5 W
Power dissipation 5.5 W
Power supply distance
rating
4
(The controller must be within four slot positions of the
power supply.)
Isolation voltage 30V (continuous), Basic Insulation Type
Type tested at 710V dc for 60 s, RS232 to system, ENET to
system, RS232 to ENET
North American temp code T4A
IEC temp code T4
Replacement battery 1769-BA
Weight, approx. 0.30 kg (0.66 lb)
Programming cable 1747-CP3 or 1756-CP3
