6 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020D-EN-P - October 2008
Before You Begin
Consider the following when planning your CompactLogix system:
• The CompactLogix controller is always the leftmost module in the
system.
• The controller must be within four modules of the system power
supply. Some I/O modules may be up to eight modules away from the
power supply. See the documentation for your 1769 I/O modules for
details.
• The 1769-L32E controller supports as many as 16 I/O modules and
the 1769-L35E controller supports as many as 30 I/O modules. Both
controllers can use a maximum of 3 I/O banks with 2 expansion
cables.
• Each I/O bank requires its own power supply.
• Only one controller can be used in a CompactLogix system.
• A 1769-ECR right end cap or 1769-ECL left end cap is required to
terminate the end of the communication bus.
Parts List
These components ship with the controller.
You may also use these components with the controller.
Component Description
1769-BA battery
1747-KY controller key
If you want to Then use this component
Connect a device to the RS-232 port 1756-CP3 or 1747-CP3 serial cable
Connect a device to the EtherNet/IP port Standard Ethernet cable with RJ-45 connector
Add nonvolatile memory 1784-CF64 or 1784-CF128 Industrial
CompactFlash card
