38 1769-L32E, 1769-L35E CompactLogix Controller
Publication
1769-IN020D-EN-P - October 2008
Relative humidity
IEC 60068-2-30 (Test Db,
Unpackaged Damp Heat)
5...95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc,
Operating)
5 g @ 10...500 Hz
Operating shock
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
DIN rail mount: 20 g; Panel mount: 30 g
Nonoperating shock
IEC 60068-2-27 (Test Ea,
Unpackaged Shock)
DIN rail mount: 30 g; Panel mount: 40 g
Emissions (CISPR 11) Group 1, Class A
ESD immunity
IEC 61000-4-2
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 1890 MHz
10V/m with 1 kHz sine-wave 80%AM from 30…2000 MHz
3V/m with 1 kHz sine-wave 80%AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4
+
2 kV at 5 kHz on communication ports
Surge transient immunity
IEC 61000-4-5
±2 kV line-earth(CM) on communication ports
Conducted RF Immunity
IEC 61000-4-6
10v rms with 1kHz sine-wave 80% AM from 150 kHz…80
MHz
1769-L32E, 1769-L35E - Environmental Specifications
Attribute 1769-L32E 1769-L35E
