12 Rockwell Automation Publication 1756-UM004C-EN-P - June 2021
Chapter 1 ControlLogix EtherNet/IP Network Device Overview
EtherNet/IP Network
The Ethernet Industrial (EtherNet/IP) network protocol is an open industrial-
networking standard that supports both real-time I/O messaging and message
exchange. The EtherNet/IP network uses
off-the-shelf Ethernet communication chips and physical media.
If you need to Select this interface
Control I/O modules and drives
Act as an adapter for I/O on remote EtherNet/IP links
Communicate with other EtherNet/IP devices (messages and HMI)
Bridge EtherNet/IP links to route messages to devices on other networks
1756-EN2F, 1756-EN2FK
1756-EN2T, 1756-EN2TK, 1756-EN2TXT
1756-EN2TP, 1756-EN2TPK, 1756-EN2TPXT
1756-EN2TR, 1756-EN2TRK, 1756-EN2TRXT
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
1756-ENBT, 1756-ENBTK
Support device level ring (DLR) and linear topologies 1756-EN2TR, 1756-EN2TRK, 1756-EN2TRXT
1756-EN3TR, 1756-EN3TRK
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Support for Parallel Redundancy Protocol 1756-EN2TP, 1756-EN2TPK
1756-EN2TPXT
Support for Redundant Adapters
(1)
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Provide control in environments where temperatures range from -25…70 C (-13…158 F) 1756-EN2TPXT
1756-EN2TRXT
1756-EN2TXT
1756-EN4TRXT
Secure access to a control system from within the plant network 1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Use an Internet browser to remotely access tags in a ControlLogix controller
Communicate with other EtherNet/IP or generic Ethernet devices (messaging only; no I/O control)
Bridge EtherNet/IP links to route messages to devices on other networks
1756-EWEB, 1756-EWEBK web server
(1) Redundant Adapters require version 3.001 and higher firmware. See the Product Compatibility and Download Center (PCDC) for that firmware.
