Chapter 1 ControlLogix EtherNet/IP Network Device Overview
Figure 6 - Message Communication Off
The content of onArray must match Figure 7.
Figure 7 - offArray
There are two additional tables to store result of IANA port administrator state
change operation.
Figure 8 - onArrayOut
