Rockwell Automation Allen-Bradley Guardmaster 442G-MABE1

Rockwell Automation Publication 442G-UM002B-EN-P - August 2021 35
Chapter 4
Status and Troubleshooting
Figure 19 - Status Indicators and DIP Switches
Lock
DIA
State
Power
Act 2
Lnk 2
Net
Mod
Pwr
Lnk 1
Act 1
X1 X4X3X2
Cover for DIP switches
3
6
12
5
1
2
34
4
3
6
1
2
51
2
34
4
n.c.
DHCP
IP-Bit 7
IP-Bit 6
IP-Bit 5
IP-Bit 4
IP-Bit 3
IP-Bit 2
IP-Bit 1
IP-Bit 0
OFF
ON
ON
OFF
See Table 4 on page 37 for lock
module status indicators.
See Table 2 on page 36
for network status indicators.
See Table 3 on page 36
for DIP switch assignment.
