Rockwell Automation Allen-Bradley Guardmaster 442G-MABE1

Rockwell Automation Publication 442G-UM002B-EN-P - August 2021 9
Chapter 1 Product Overview
Assembly Overview Figure 1 - Components at a Glance
Figure 2 - Bus Module
Figure 3 - Locking Module with Control Cover
Bus Module
Escape Release
(optional)
Lock Module
Mounting Plates
Handle Assembly
Power Connectors
Status Indicators
Ethernet Connectors
Connector for
Attaching an Enabling
Switch (select models)
Status/Diagnostic
Status Indicators
1 x Torx T8
Marking for Maximum
Mounting Distance
Locking Arm
Manual Release Cover
