Rockwell Automation Allen-Bradley Kinetix TLP Series User Manual

Rockwell Automation Publication TLP-IN001A-EN-P - October 2019 9
Kinetix TLP Servo Motors with 046…235 mm Frame Size
Connector Data
This section identifies the power, feedback, and brake pins on the motor connectors.
The motor power connector pinouts apply to the motor catalog numbers listed.
Motor Power Connector Pinouts
Motor Brake Connector Pinout
Motor Feedback Connector Pinouts
Pin Signal Motor Cat. No.
1U
TLP-A046
TLP-A070
TLP-A090
TLP-A100
2V
3BR+
4W
5
6BR–
1
2
6
5
4
3
Pin Signal Motor Cat. No.
A–
TLP-A115
TLP-A145
BW
C–
D–
E
FU
GBR+
HBR–
IV
A
B
C
D
E
F
G
H
I
Pin Signal Motor Cat. No.
ABR+
TLP-A200-200
TLP-A200-300
TLP-A200-350
TLP-A200-450
BBR–
C–
DU
EV
FW
G
H–
J–
A
B
C
D
E
F
G
H
I
Pin Signal Motor Cat. No.
AU
TLP-A200-550
TLP-A200-750
TLP-A235-11K
TLP-A235-15K
BV
CW
D
A
B
C
D
Pin Signal Motor Cat. No.
A BR+ TLP-A200-550
TLP-A200-750
TLP-A235-11K
TLP-A235-15K
BBR–
A
B
Pin Signal Motor Cat. No.
1T+
TLP-A046
TLP-A070
TLP-A090
TLP-A100
2BAT+
3–
4T–
5BAT–
6–
7DC+5V
8
9SHIELD
1
2
6
5
4
3
9
8
7
Pin Signal Motor Cat. No.
AT+
TLP-A115
TLP-A145
TLP-A200
TLP-A235
BT–
CBAT+
DBAT–
E…K –
LSHIELD
M…P –
R
SDC+5V
T–
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
S
T
