1st Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
General Status 06 Reply Data Too Large
Extended Status Size 00 No extended status
Reply Data C2 00 SINT Tag Type Value
nn nn nn…nn Data for Elements 0 through 489
2nd Message Request Field Bytes (in hex) Description - Symbolic Segment Addressing
Request Service 52 Read Tag Fragmented Service (Request)
Request Path Size 06 Request Path is 6 words (12 bytes) long
Request Path 91 0A 54 6F 74 61 6C 43 6F 75 6E 74 ANSI Ext. Symbolic Segment for TotalCount
Request Data D6 06 Number of elements to read (1750)
EA 01 00 00 Start at this byte offset (490) and return as much as will fit
2nd Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
Reply Service D2 Read Tag Fragmented Service (Reply)
Reserved 00
General Status 06 Reply Data Too Large
Extended Status Size 00 No extended status
Reply Data C2 00 SINT Tag Type Value
nn nn nn…nn Data for Elements 490 through 979
3rd Message Request Field Bytes (in hex) Description - Symbolic Segment Addressing
Request Service 52 Read Tag Fragmented Service (Request)
Request Path Size 06 Request Path is 6 words (12 bytes) long
Request Path 91 0A 54 6F 74 61 6C 43 6F 75 6E 74 ANSI Ext. Symbolic Segment for TotalCount
Request Data D6 06 Number of elements to read (1750)
D4 03 00 00 Start at this offset (980) and return as much as will fit
3rd Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
Reply Service D2 Read Tag Fragmented Service (Reply)
Reserved 00
General Status 06 Reply Data Too Large
Extended Status Size 00 No extended status
Reply Data C2 00 SINT Tag Type Value
