30 Rockwell Automation Publication 1756-PM020F-EN-P - January 2019
2nd Message Request Field Bytes (in hex) Description - Symbolic Segment Addressing
nn, nn, …nn Element Data for Elements 474 through 947
2nd Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
Reply Service D3 Write Tag Fragmented Service (Reply)
Reserved 00
General Status 00 Success
Extended Status Size 00 No extended status
3rd Message Request Field Bytes (in hex) Description - Symbolic Segment Addressing
Request Service 53 Write Tag Fragmented Service (Request)
Request Path Size 06 Request Path is 6 words (12 bytes) long
Request Path 91 0A 54 6F 74 61 6C 43 6F 75 6E 74 ANSI Ext. Symbolic Segment for TotalCount
Request Data C2 00 SINT Tag Type Value
D6 06 Total number of elements to write (1750)
B4 03 00 00 Start at this offset
nn, nn, …nn Element Data for Elements 948 through 1421
3rd Message Reply Field Bytes (in hex) Description - Symbolic Segment Addressing
Reply Service D3 Write Tag Fragmented Service (Reply)
Reserved 00
General Status 00 Success
Extended Status Size 00 No extended status
4th Message Request Field Bytes (in hex) Description - Symbolic Segment Addressing
Request Service 53 Write Tag Fragmented Service (Request)
Request Path Size 06 Request Path is 6 words (12 bytes) long
Request Path 91 0A 54 6F 74 61 6C 43 6F 75 6E 74 ANSI Ext. Symbolic Segment for TotalCount
Request Data C2 00 SINT Tag Type Value
D6 06 Total number of elements to write (1750)
8E 05 00 00 Start at this Offset
nn, nn, …nn Element Data for Elements 1422 through 1749
