CIP Services and User-created Tags
Rockwell Automation Publication 1756-PM020F-EN-P - January 2019 61
Message Reply Field Bytes (in hex) Description
00 00 Success
03 B2 80 C5 Attribute value (DINT)
04 00 Attribute Number (Attribute 4)
00 00 Success
03 B2 80 C5 Attribute value (DINT)
0A 00 Attribute Number (Attribute 10)
00 00 Success
F8 DE 47 B8 Attribute value (DINT)
The CPU Lock feature of Logix 5000 controllers causes this service request
to return a General Status 0x10, Device State Conflict when the controller is
password locked. In this state, controller memory can not be altered.
Rockwell Automation suggests after receipt of the Device State Conflict for
the first time, the client application should refresh the tag information one
time. The client application should refresh again if the connection lost. The
client application should reconnect after receipt of General Status 0x05, or a
successful response to the service that indicates the CPU is unlocked.
See also
Step 5: Determining when the tags list and structure information need
refreshing on page 59
