Energy Pause Function Chapter 5
Interaction Between Logic Command and Digital Input
Parameter 0:267 [EnergyPauseOwner] indicates which ports are issuing valid
energy pause commands. By default, bit 15 = 1, which is the embedded Ethernet
port.
When both methods (logic command and digital input) are used, an OR
function of the two signals determines the Energy Pause request. An Energy
Pause request results if either signal detects the request. A Resume request results
if both signals are cleared.
Table 8 - Energy Pause Request Results
Logic Command Bit 21 ‘Energy Pause’ DI Energy Pause Digital Input Request Result
0 (cleared) 0 (open or de-energized) Resume Command
0 (cleared) 1 (closed or energized) Energy Pause Command
1 (set) 0 (open or de-energized) Energy Pause Command
1 (set) 1 (closed or energized) Energy Pause Command
