48 Rockwell Automation Publication 750-RM100A-EN-P - August 2019
Chapter 6 Predictive Maintenance
Reset Examples
This section provides instructions about how to reset Predictive Maintenance
function parameters after you replace a component.
M0 Power Module Heatsink Fan Example
Follow these steps to reset the Elapsed Life and Remaining Life parameters for
the heatsink fan in the M0 power module in the motor side inverter.
1. Go to port 0 and open parameter 0:504 [PredMain Rst En]. Set bit 10
‘M0’.
2. Go to the Predictive Main group in the M0 Power Module file in port 12.
3. Find parameter 12:130 [M0PredMaintReset]. Then select 1 ‘M HSFan
Life’ in the drop-down menu.
Parameter 12:130 [M0PredMaintReset] returns to 0 ‘Ready’ after the reset
is performed.
4. Return to parameter 0:504 [PredMain Rst En] in port 0. Then clear bit 10
‘M0’.
