64 Rockwell Automation Publication PFLEX-AP005A-EN-P - October 2010
Chapter 3 Network Communications
20-COMM Carrier Adapters
The following table details what 20-COMM adapters can be used with the
PowerFlex 750-Series drives.
Table 33 - 20-COMM Adapters Compatible with the PowerFlex 750-Series Drives
PowerFlex 750-Series Communication Options
Communication options currently available for the PowerFlex 750-Series drives
are ControlNet and DeviceNet, both which will network the drive with enhanced
features beyond what 20-COMM adapters provide. For additional information,
see the PowerFlex 750-Series Drive DeviceNet Option Module User Manual,
publication 750COM-UM002
, and the PowerFlex 20-750-CNETC Coaxial
ControlNet Option Module User Manual, publication 750COM-UM003
.
20-COMM-x Adapter Type
Can It Access
Ports 2, 3, & 6
for I/O
Connections?
(1)
(1) Ports for implicit and explicit messaging.
Can It
Access
Ports 7…14
Devices?
Does It
Support
Drive Add-
on Profiles?
Does It
Support
Asian
Languages?
(9)
(9) Chinese, Japanese, and Korean languages are currently supported.
B BACnet MS/TP No No No No
C ControlNet (Coax) Yes
(2)
(2) Controller must be capable of reading/writing 32-bit floating point (REAL) values.
Yes
(4)
(4) Requires firmware version 3.001 or higher.
Yes
(8)
(8) Requires firmware version 1.05 or higher for add-on profiles and version 16 or higher for RSLogix 5000.
Yes
(4)
D DeviceNet Yes
(2)
Yes
(5)
(5) Requires firmware version 2.005 or higher.
No No
E EtherNet/IP Yes
(2)
Yes
(6)
(6) Requires firmware version 4.001 or higher.
Yes
(8)
Yes
(6)
H RS-485 HVAC Yes
(3)
(3) Only works with Modbus RTU mode.
No No No
I Interbus Yes
(2)
No No No
K CANopen Yes
(2)
No No No
L LonWorks No No No No
M Modbus/TCP Yes
(2)
Yes
(7)
(7) Requires firmware version 2.001 or higher.
No Yes
(7)
P Profibus DP Yes
(2)
No No No
Q ControlNet (Fiber) Yes
(2)
Yes
(4)
Yes
(8)
Yes
(4)
R Remote I/O Yes
(2)
Yes
(5)
No No
S RS-485 DF1 Yes
(2)
No No No
