32 Rockwell Automation Publication PFLEX-AP005A-EN-P - October 2010
Chapter 1 Drive Selection Considerations
PowerFlex 750-Series Drives
Table 11 - PowerFlex 750-Series Frames 2…5 Power Terminal Block Specifications
Table 12 - PowerFlex 750-Series Frames 6 & 7 Terminal Block Specifications
Table 13 - PowerFlex 750-Series Frames 2…7 PE Grounding Stud Specifications
Frame
Wire Size Range
(1)
(2)
(1) Maximum/minimum wire sizes that the terminal block will accept—these are not recommendations.
(2) Terminal blocks are designed to accept a single wire.
Strip Length
Recommended
Torque Recommended Tool(s)
Maximum Minimum
2 4.0 mm
2
(10 AWG)
0.2 mm
2
(24 AWG)
8.0 mm
(0.31 in.)
0.5 N•m
(4.4 lb•in)
#1 flat screwdriver
316.0 mm
2
(6 AWG)
0.5 mm
2
(20 AWG)
10.0 mm
(0.39 in.)
1.2 N•m
(10.6 lb•in)
#2 flat screwdriver
425.0 mm
2
(3 AWG)
2.5 mm
2
(14 AWG)
10.0 mm
(0.39 in.)
2.7 N•m
(24 lb•in)
#2 Pozidrive®
492-C Phillips®
0.25 in. flat screwdriver
535.0 mm
2
(1 AWG)
10.0 mm
2
(8 AWG)
12.0 mm
(0.5 in.)
4.0 N•m
(35 lb•in)
#2 Pozidrive®
492-C Phillips®
0.25 in. flat screwdriver
Frame
Maximum
Lug Width
Recommended
Torque Terminal Bolt Size Recommended Tool
6 34.6 mm
(1.36 in.)
11.3 N•m
(100 lb•in)
M8 x 1.25 13 mm hex socket
7 43.5 mm
(1.71 in.)
11.3 N•m
(100 lb•in)
M8 x 1.25 13 mm hex socket
Frame Recommended Torque Terminal Bolt Size Recommended Tool
2 1.36 N•m (12 lb•in) M4 7 mm hex deep-socket
3 3.4 N•m (30 lb•in) M6 10 mm hex deep-socket
4 3.4 N•m (30 lb•in) M6 10 mm hex deep-socket
5 3.4 N•m (30 lb•in) M6 10 mm hex deep-socket
6 11.3 N•m (100 lb•in) M8 13 mm hex socket
7 11.3 N•m (100 lb•in) M8 13 mm hex socket
