Page #80 background image
3-34 Programming and Parameters
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Advanced Program Group (continued)
A113 [Anlg In4-20mA Hi] Related Parameter(s): d021, P035, P038
Sets the analog input level that corresponds to P035 [Maximum Freq] if a 4-20mA input is used by
P038
[Speed Reference].
Analog inversion can be accomplished by setting this value smaller than A112 [Anlg In4-20mA Lo].
Values Default: 100.0%
Min/Max: 0.0/100.0%
Display: 0.1%
A114 [Slip Hertz @ FLA] Related Parameter(s): P033
Compensates for the inherent slip in an induction motor. This frequency is added to the commanded
output frequency based on motor current.
Values Default: 2.0 Hz
Min/Max: 0.0/10.0 Hz
Display: 0.1 Hz
A115 [Process Time Lo] Related Parameter(s): d010, P034
Scales the time value when the drive is running at P034 [Minimum Freq]. When set to a value other
than zero, d010
[Process Display] indicates the duration of the process.
Values Default: 0.00
Min/Max: 0.00/99.99
Display: 0.01
A116 [Process Time Hi] Related Parameter(s): d010, P035
Scales the time value when the drive is running at P035 [Maximum Freq]. When set to a value other
than zero, d010
[Process Display] indicates the duration of the process.
Values Default: 0.00
Min/Max: 0.00/99.99
Display: 0.01
A117 [Bus Reg Mode]
Controls the operation of the drive voltage regulation, which is normally operational at decel or when
the bus voltage rises.
Refer to the Attention statement on page P-3
for important information on bus regulation.
Options 0 “Disabled”
1 “Enabled” (Default)
A118 [Current Limit 2] Related Parameter(s): P033, A051-A054, A089
Maximum output current allowed before current limiting occurs. This parameter is only active if
A051
- A054 [Digital Inx Sel] is set to 25 “Current Lmt2” and is active.
Values Default: Drive Rated Amps × 1.5
Min/Max: 0.1/(Drive Rated Amps × 1.8)
Display: 0.1 Amps
22B-UM001.book Page 34 Tuesday, May 30, 2017 5:22 PM
