FlexPak 3000 DC Drive OIM User’s Guide
CML
Tuning
CML PI PROP GAIN
(P.301)
CML PI LEAD FREQUENCY
(P.302)
CML REF RATE LIMIT
(P.303)
POSITIVE CURRENT LIM
(P.005)
NEGATIVE CURRENT LIM
(P.006)
Self Tuning Setup
SELF TUNE BRIDGE
(P.220)
SELF TUNE FIELD RANGE
(P.218)
SELF TUNE STABILITY
(P.219)
Self Tuning
POS CURRENT LIM SEL
(P.223)
NEG CURRENT LIM SEL
(P.224)
CML Feedback Scaling
MAXIMUM CURRENT
(P.007)
MOTOR RATED ARM AMPS
(P.008)
CML FEEDBACK GAIN ADJ
(P.300)
J
18
ARM I FB RESISTOR
(P.395)
CT TURNS RATIO
(P.010)
CML FEEDBACK
(P.397)
Three Phase AC Line
NOMINAL AC LINE FREQ
(P.306)
NOMINAL AC LINE VOLTS
(P.307)
AC LINE PERIOD
(P.393)
AC LINE VOLTAGE
(P.392)
PLL MAXIMUM ERROR
(P.308)
SCR
Diagnostics
OPEN SCR SENSITIVITY
(P.600)
OPEN SCR TRIP THRESH
(P.601)
