OIM Menu Structure
A-9
DIG OUT
2
SELECT
(P.411)
DIG OUT
2
CONTACT TYP
(P.412)
Frequency I/O
I
/
O EXPANSION KIT
(P.797)
FREQ IN ZERO
(P.423)
FREQ IN FULL SCALE
(P.424)
FREQ IN
(P.491)
FREQ OUT SELECT
(P.425)
FREQ OUT ZERO
(P.426)
FREQ OUT FULL SCALE
(P.427)
Level Detectors
LEVEL DETECT
1
SELECT
(P.602)
LEVEL DETECT
1
THRESH
(P.603)
LEVEL DETECT
1
DELAY
(P.604)
LEVEL DETECT
1
OUTPUT
(P.648)
LEVEL DETECT
2
SELECT
(P.605)
LEVEL DETECT
2
THRESH
(P.606)
LEVEL DETECT
2
DELAY
(P.607)
LEVEL DETECT
2
OUTPUT
(P.649)
Network Communications
NETWORK KIT
(P.796)
NETW TYPE
&
VERSION
(P.909)
NETW COMM STATUS
(P.908)
NETW DROP NUMBER
(P.900)
NETW COMM LOSS SELECT
(P.901)
NETW CONNECT TYPE
(P.910)
AMX NETW REF SELECT
(P.911)
NETW OUT REG
1
SELECT
(P.902)
NETW OUT REG
2
SELECT
(P.903)
NETW OUT REG
3
SELECT
(P.904)
NETW IN REG
1 (P.905)
