PowerFlex 753 Drive (P_PF753)
Sts_BypActive BOOL 1 = Bypassing active (Bypassed or Maintenance).
Sts_Disabled BOOL 1 = Drive is disabled.
Sts_NotRdy BOOL 1 = Motor is Not Ready to Run (independent of mode), check interlocks and permissives.
Nrdy_Disabled BOOL 1 = Device Not Ready:
• Device disabled by Maintenance
• Configuration error
• Interlock not OK
• Permissive not OK
• Operator State 0 priority command requires reset
• Device Failure (Shed Requires Reset)
• I/O Fault (Shed requires reset)
• Device tripped (Drive Fault)
• Drive not ready
• Device Logic disabled/no mode
Nrdy_CfgErr
Nrdy_Intlk
Nrdy_Perm
Nrdy_OperPrio
Nrdy_Fail
Nrdy_IOFault
Nrdy_Trip
Nrdy_DriveNR
Nrdy_NoMode
Sts_MaintByp BOOL 1 = A Maintenance Bypass is active, display icon.
Sts_AlmInh BOOL 1 = An alarm is Shelved, Disabled or Suppressed, display icon.
Sts_Err BOOL 1 = Error in configuration: see detail bits for reason.
Err_Timer BOOL 1 = Error in configuration: Invalid Check or Reset Pulse Time (use 0…2,147,483).
Err_Sim BOOL 1 = Error in configuration: simulation timer preset: use 0…2,147,483).
Err_Alarm BOOL 1 = Error in configuration: Alarm Minimum On time or severity.
Err_FdbkRaw BOOL 1 = Error in configuration: Speed feedback raw minimum = maximum.
Err_FdbkEU BOOL 1 = Error in configuration: Speed feedback engineering units minimum = maximum.
Err_RefLim BOOL 1 = Error in configuration: Speed Ref Limit minimum > maximum.
Err_RefEU BOOL 1 = Error in configuration: Speed Ref engineering units minimum = maximum.
Err_RefRaw BOOL 1 = Error in configuration: Speed Ref Raw minimum = maximum.
Sts_Hand BOOL Mode.Sts_Hand 1 = Mode is Hand (supersedes Operator, Program, Override, and Maintenance).
Sts_Maint BOOL Mode.Sts_Maint 1 = Mode is Maintenance (supersedes Operator, Program, and Override).
Sts_Ovrd BOOL Mode.Sts_Ovrd 1 = Mode is Override (supersedes Operator and Program).
Sts_Prog BOOL Mode.Sts_Prog 1 = Mode is Program (automatic).
Sts_Oper BOOL Mode.Sts_Oper 1 = Mode is Operator (manual).
Sts_ProgOperLock BOOL Mode.Sts_ProgOperLock 1 = Program or operator has requested mode Lock.
Sts_NoMode BOOL Mode.Sts_NoMode 1 = No mode (disabled because EnableIn is False).
Sts_MAcqRcvd BOOL Mode.Sts_MAcqRcvd 1 = Maintenance Acquire command received this scan.
Sts_FailToStart BOOL FailToStart.Inp 1 = Drive failed to start.
Sts_FailToStop FailToStop.Inp 1 = Drive failed to stop.
Sts_IntlkTrip IntlkTrip.Inp 1 = Drive was stopped by an Interlock Not OK (One-Shot).
Sts_DriveFault DriveFault.Inp 1 = Drive Fault (see drive display or manual).
Sts_IOFault IOFault.Inp I/O Comm Fault status (0 = OK, 1 = Bad).
