Rockwell Automation Publication SYSLIB-RM044D-EN-P - February 2017 53
PowerFlex 753 Drive (P_PF753)
Enable navigation to
run reverse
permissive object
Check if a permissive object is
connected to Inp_RevPermOK. The
Permissive indicator becomes a
button that opens the permissive
faceplate.
IMPORTANT: The name of the
Reverse Permissive object in the
controller must be this object's
name with the suffix ‘_RevPerm’. For
example, if your P_PF753 object has
the name ’Drive123’, then its Reverse
Permissive object must be named
‘Drive123_RevPerm’.
Engineering
Configuration
(Code E)
Cfg_HasRevPermObj
Enable navigation to
interlock object
Check if an interlock object is
connected to Inp_IntlkOK. The
Interlock indicator becomes a button
that opens the interlock faceplate.
IMPORTANT: The name of the
Interlock object in the controller
must be this object's name with the
suffix ‘_Intlk’. For example, if your
P_PF753 object has the name
’Drive123’, then its Interlock object
must be named ‘Drive123_Intlk’.
Cfg_HasIntlkObj
Enable navigation to
restart inhibit object
Check if a restart inhibit object is
connected. The button that opens
the Restart Inhibit faceplate
appears.
IMPORTANT: The name of the
Restart Inhibit object in the
controller must be this object's
name with the suffix ‘_ResInh’. For
example, if your P_PF753 object has
the name ’Drive123’, then its Restart
Inhibit object must be named
‘Drive123_ResInh’.
Cfg_HasResInhObj
Enable navigation to
runtime object
Check if a runtime object is
connected. The button that opens
the runtime faceplate appears.
IMPORTANT: The name of the
runtime object in the controller
must be this object's name with the
suffix ‘_RunTime’. For example, if
your P_PF753 object has the name
‘Drive123’, then its runtime object
must be named
‘Drive123_RunTime’.
Cfg_HasRunTimeObj
Table 19 - Engineering Tab Page 3 Description
Function Action Security Configuration Parameters
