CHAPTER 7
Troubleshooting
This chapter contains information for diagnosing and correcting potential problems.
7.1 Locating the COMM Status Indicator
The VSM500 Integrated drive/motor has a COMM status indicator that you can use to
determine the status of the VSM500 unit and DeviceNet communications.
Figure 7.1 – VSM500 Integrated Drive/Motor COMM Status Indicator
COMM Status
Indicator
