Technical Specifications
A-1
APPENDIX A
Technical Specifications
Electrical
Network Supply Voltage: 11 to 25 VDC
Power Consumption: 0.5 Watt maximum
Node Current Consumption: 40 mA (Use this value to size the network current draw
from the power supply.)
Environmental
Ambient Temperature
Operating: 0 to 40 °C (32 to 104 °F)
Storage: -40 to 85 °C (-40 to 185 °F)
Relative Humidity: 0 to 95% non-condensing
Vibration: 1.0 G Operational
2.5 G Non-operational
Shock: 15.0 G Operational
30.0 G Non-operational
Altitude: 1,000 m (3,300 ft.) without derating
Communications
Protocol: DeviceNet
Data Rates: 125, 250, 500 k BPS
Distance maximum: 500 m (1640 ft.) @ 125 k BPS
200 m (820 ft.) @ 250 k BPS
100 m (328 ft.) @ 500 k BPS
Mechanical
Dimensions
Height: 120.65 mm (4.75 in.)
Width: 155.57 mm (6.125 in)
Depth: 12.70 mm (0.5 in.)
