Parameters
B-1
APPENDIX B
Parameters
Appendix B contains a list of the parameters in the VSM500 Integrated drive/motor
and the DeviceNet option board.
B.1 Product Codes and EDS Files
Catalog Number
Power
Rating (HP) Voltage
Motor
Frame Version
Product
Code EDS File
10XS1011 1 115V, 1 Phase 56C Std 137 137.cod/3.eds
10XW1011 1 115V, 1 Phase 56C Loc 138 138.cod/3.eds
11XS1011 1 115V, 1 Phase 143TC Std 139 139.cod/3.eds
11XW1011 1 115V, 1 Phase 143TC Loc 140 140.cod/3.eds
10XS3011 1 230V, 1 Phase 56C Std 141 141.cod/3.eds
10XW3011 1 230V, 1 Phase 56C Loc 142 142.cod/3.eds
11XS3011 1 230V, 1 Phase 143TC Std 143 143.cod/3.eds
11XW3011 1 230V, 1 Phase 143TC Loc 144 144.cod/3.eds
21XS3011 2 230V, 1 Phase 145TC Std 145 145.cod/3.eds
21XW3011 2 230V, 1 Phase 145TC Loc 146 146.cod/3.eds
10XS2011 1 230V, 3 Phase 56C Std 147 147.cod/3.eds
10XW2011 1 230V, 3 Phase 56C Loc 148 148.cod/3.eds
11XS2011 1 230V, 3 Phase 143TC Std 149 149.cod/3.eds
11XW2011 1 230V, 3 Phase 143TC Loc 150 150.cod/3.eds
21XS2011 2 230V, 3 Phase 145TC Std 151 151.cod/3.eds
21XW2011 2 230V, 3 Phase 145TC Loc 152 152.cod/3.eds
10XS4011 1 460V, 3 Phase 56C Std 153 153.cod/3.eds
10XW4011 1 460V, 3 Phase 56C Loc 154 154.cod/3.eds
11XS4011 1 460V, 3 Phase 143TC Std 155 155.cod/3.eds
11XW4011 1 460V, 3 Phase 143TC Loc 156 156.cod/3.eds
21XS4011 2 460V, 3 Phase 145TC Std 157 157.cod/3.eds
21XW4011 2 460V, 3 Phase 145TC Loc 158 158.cod/3.eds
32XS4011 3 460V, 3 Phase 182TC Std 159 159.cod/3.eds
32XW4011 3 460V, 3 Phase 182TC Loc 160 160.cod/3.eds
52XS4011 5 460V, 3 Phase 184TC Std 161 161.cod/3.eds
52XW4011 5 460V, 3 Phase 184TC Loc 162 162.cod/3.eds
