Rockwell DeviceNet - B.3 Parameter List

Parameters B-3
B.3 Parameter List
#
Object
Mapping Name and Description
Access
Rule
1
Units/
Range
Factory
Default
Drive Display Parameters
01 0x0F-1-1 Command Frequency
Value of the presently selected speed reference.
Get 0.1 Hz None
02 0x0F-2-1 Output Frequency
Output frequency to the motor.
Get 0.1 Hz None
03 0x0F-3-1 Output Voltage
Output voltage to the motor.
Get 1 Volt None
04 0x0F-4-1 Output Current
Output current to the motor.
Get 0.1% of
Rated
Current
None
05 0x0F-5-1 Load Current
Output current to the motor due to the load.
Get 0.1% of
Rated
Current
None
06 0x0F-6-1 Bus Voltage
DC Bus voltage level.
Get 1 Volt None
07 0x0F-7-1 Power Unit Temperature
Temperature of the VSM500 unit.
Get 1 °C None
08 0x0F-8-1 Analog Input
The value of the analog speed reference input (terminal 2 or 3 on the
control signal terminal block).
Get 0.1% of
Full
Scale
None
09 0x0F-9-1 TB Input Status
The on (1) and off (0) state of the inputs to the control signal terminal block:
Get Bits None
10 0x0F-10-1 Last Fault
Fault number for the most recent fault.
0 = No Fault
1 = Function Loss
2 = Over Current
3 = Motor Overload
4 = Over Voltage
5 = Under Voltage Stop
6 = Over Temperature
7 = Communication Loss
8 = Parameter Checksum
9 = EEPROM Drive ID
Refer to Chapter 7 for troubleshooting
10 = Keypad Disconnect
11 = Keypad Fixed Pattern
12 = Keypad Redundant Start
13 = TB Redundant Start
14 = Keypad Connect
15 = Under Voltage Running
20 = DNet EEPROM Fault
21 = DNet Unrecoverable Fault
22 = No DNet Power
2 3 = D N e t L o s t I / O C o n n e c t i o n
24 = DNet Forced Fault
procedures.
Get 0 to 24 None
1
Get = Read. Set = Write. Set access is allowed only if DIP switch 10 on the VSM500 Integrated drive/motor is set to On (figure 2.3).
2
The parameter can be set only when the drive is stopped.
3
The parameter can be set only then the VSM500 Integrated drive/motor does not have an active I/O connection.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0Bit 8Bit 9Bit 10Bit 11Bit 12Bit 13Bit 14Bit 15
Stop
Start
Reset
Forward/Reverse
Function Loss
RPM/Percent Load
Not Used
Not UsedSpeed Preset 0
Speed Preset 1
Speed Preset 2
Not Used
