B-6
VSM500 DeviceNet Option Board
Object
Mapping Name and Description
Access
Rule
1
Units/
Range
Factory
Default
Drive Program Parameters (continued)
49 0x0F-49-1 Analog Maximum
The percent of analog input used to represent parameter 31 [MAXIMUM
FREQUENCY]. If the maximum analog input equals maximum frequency, no
action is needed. If it is desired to adjust the analog input to equal
parameter 31 [MAXIMUM FREQUENCY], use parameter 08 [ANALOG INPUT] to
adjust the analog input to the desired level and then enter the value in
parameter 49.
Get/
Set
2
0.0% to
100.0%
100.0%
50 0x0F-50-1 Fault Reset
Resets the drive after a fault. This parameter is a command. It will be reset
to 0 = No Action after the command is completed.
0 = No Action
1 = Reset Fault
Get/
Set
2
0 to 1 0
51 0x0F-51-1 Preset Speed 1
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
10.0 Hz
52 0x0F-52-1 Preset Speed 2
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
20.0 Hz
53 0x0F-53-1 Preset Speed 3
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
30.0 Hz
54 0x0F-54-1 Preset Speed 4
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
40.0 Hz
55 0x0F-55-1 Preset Speed 5
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
50.0 Hz
56 0x0F-56-1 Preset Speed 6
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
60.0 Hz
57 0x0F-57-1 Preset Speed 7
Programmed value that sets the frequency that the drive outputs when this
preset is selected.
Get/
Set
0.0 Hz to
120.0 Hz
70.0 Hz
DeviceNet Parameters
101 0x0F-101-1 Switches MAC ID
The state of the node address DIP switches (1 - 6). This address may not
reflect the present address of the module if the baud rate DIP switches are
set to 3. In this case, parameter 103 [
NV MAC ID] is used.
Get 0 to 63 63
102 0x0F-102-1 Switches Baud
The state of the baud rate DIP switches (7 - 8).
0 = 125K BPS
1 = 250K BPS
2 = 500K BPS
3 = Use nonvolatile parameters for node address and baud rate settings.
Get 0 to 3 0
1
Get = Read. Set = Write. Set access is allowed only if DIP switch 10 on the VSM500 Integrated drive/motor is set to On (figure 2.3).
2
The parameter can be set only when the drive is stopped.
3
The parameter can be set only then the VSM500 Integrated drive/motor does not have an active I/O connection.
