C-6
VSM500 DeviceNet Option Board
C.5 Class Code 0x04 – Assembly Object
Class Attributes
Instance 1 to 106 Attributes: I/O Instances
Common Services
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 106
Attribute ID Access Rule Name Data Type Min/Max Default Description
3 Get Data See instance data format for individual I/O
assemblies on pages C-7 to C-9.
Service Code
Implemented for
Service NameClass Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
