DeviceNet Objects
C-11
Instance 2 Attributes: Polled I/O Connection
Attribute
ID
Access
Rule Name
Data
Type Value
1 Get State USINT 0 = Nonexistent
1 = Configuring
3 = Established
4 = Timed out
2 Get Instance Type USINT 1 = I/O Message
3 Get Transport Class Trigger USINT 0x83
4 Get Produced Connection ID UINT 01111xxxxxx
xxxxxx = Node Address
5 Get Consumed Connection ID UINT 10xxxxxx101
xxxxxx = Node Address
6 Get Initial Comm. Characteristics BYTE 0x01
7 Get Produced Connection Size UINT 0 to 4
8 Get Consumed Connection Size UINT 0 to 4
9 Get/Set Expected Packet Rate UINT Timer Resolution of 2 msec
12 Get/Set Watchdog Timeout Action USINT 0 = Transition to time out
1 = Auto delete
2 = Auto reset
13 Get Produced Connection Path
Length
UINT 6
14 Get Produced Connection Path 0x20, 0x04, 0x24, XX, 0x30,
0x03
1
1
Refer to the DeviceNet specification for a description of the connection path
.
15 Get Consumed Connection Path
Length
UINT 6
16 Get Consumed Connection Path 0x20, 0x04, 0x24, XX, 0x30,
0x03
1
