DeviceNet Objects
C-13
Instances 6 through 10: Explicit Message Connections
Common Services
Attribute
ID
Access
Rule Name
Data
Type Value
1 Get State USINT 0 = Nonexistent
1 = Configuring
3 = Established
4 = Timed out
5 = Deferred delete
2 Get Instance Type USINT 0 = Explicit Message
3 Get Transport Class Trigger USINT 0x83
4 Get Produced Connection ID UINT 11yyyxxxxxx
yyy = Group 3 Message ID
xxxxxx = Node Address
5 Get Consumed Connection ID UINT 11yyyxxxxxx
yyy = Group 3 Message ID
xxxxxx = Client Node
Address
6 Get Initial Comm. Characteristics BYTE 0x33
7 Get Produced Connection Size UINT 99
8 Get Consumed Connection Size UINT 159
9 Get/Set Expected Packet Rate UINT Timer Resolution of 2 msec.
12 Get/Set Watchdog Timeout Action USINT 1 = Auto delete
3 = Deferred delete
13 Get Produced Connection Path
Length
UINT 0
14 Get Produced Connection Path Null (no data)
15 Get Consumed Connection Path
Length
UINT 0
16 Get Consumed Connection Path Null (no data)
Service Code
Implemented for
Service NameClass Instance
0x05 No Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x11 Yes No Find_Next_Object_Instance
