C-16 VSM500 DeviceNet Option Board
C.8 Class Code 0x10 – Parameter Group Object
Class Attributes
Instance 1 Attributes: Drive Display Instance
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 3
8 Get Native Language USINT 0 = English
Attribute
ID
Access
Rule Name Data Type Value
1 Get Group Name String SHORT_STRING Drive Display
2 Get Number of Members in Group UINT 10
3 Get 1st Parameter Number in Group UINT 1
4 Get 2nd Parameter Number in Group UINT 2
5 Get 3rd Parameter Number in Group UINT 3
6 Get 4th Parameter Number in Group UINT 4
7 Get 5th Parameter Number in Group UINT 5
8 Get 6th Parameter Number in Group UINT 6
9 Get 7th Parameter Number in Group UINT 7
10 Get 8th Parameter Number in Group UINT 8
11 Get 9th Parameter Number in Group UINT 9
12 Get 10th Parameter Number in Group UINT 10
