SELECTING OR RETIRING A STOP
Press the bottom of the desired tilt tab to turn it on. It will light, indicating it is on. Press the top
of the tilt tab to turn offthe stop. The light will go off, indicating the stop is off.
All
of the 702 stops are controlled with lighted tilt tabs, with the exception of the Chimes on the
Great manual, which are controlled by a lighted piston located underneath the Swell manual.
Press this piston to activate the Chime stop on the Great (the piston will light). Press this piston
again to retire the Chime stop (the light will go out).
COMBINATION ACTION
(Pistons)
The 702 features a combination action easily changed by the organist from the console. The
organist can pre-select favorite registrations and make rapid changes in tone color using this
advanced system. The pistons will light when pressed.
The 702 combination action includes ten General pistons, six Great and Swell Divisional pis-
tons, three Pedal Divisional pistons, a SET piston and a GENERAL CANCEL piston with four
memory levels
(Ml, M2, M3 and M4). General pistons affect all Divisions of the organ (Great,
Swell and Pedal). Divisional pistons affect the specific Division.
/!
/
/
-
'"
