Roger PR311 - Page 11

PR311 v1.0 fv102 EN Rev.E.DOC 10/22/2007
11
used to indicate a loss of AC power supply. Each time this input is
triggered it activates the TROUBLE flag timer which can further
activate (if programmed) the TROUBLE output (code 70).
Low Battery
06
Input is dedicated for connection to an output line or a contact which is
used to indicate a loss of AC power supply. Each time this input is
triggered it activates the TROUBLE flag timer which can further
activate (if programmed) the TROUBLE output (code 70).
Bell Button
07
Each time this input is triggered controller activates the BELL Output
(code 15). Input is dedicated for connection to a button used to indicate
that somebody wants to enter the premises.
Tamper Loop
08
Input is dedicated for connection to a tamper-protection contact which
indicates that an unauthorized person attempts to open the controller's
case. Each time this input is triggered it activates the TAMPER flag
timer which can further activate (if programmed) the TAMPER output
(code 65).
Access Disabled
11
Input is dedicated for connection to a switch or an output which when
activated will disable access to the controlled door.
Ready
13
This input is dedicated for connection to an output line or to a switch
which indicates that controller can be Armed. When this input is not
triggered controller can not be armed. This input does not affect arming
when it is carried out by input Arm/Disarm Steady Switch (code 03).
Force Door Lock to ON
14
Triggering of this input will force activation of the door release. This
input is dedicated to be connected to an emergency switch which when
triggered will release door. As long as input is triggered door will be
released.
Arm/Disarm Momentary
Switch
61
Input is dedicated for connection to a button or an output which is
dedicated to rearm the controller. Each time this input is triggered the
controller turns to reverse condition (from Armed to Disarmed or vice
versa).
Set Normal Door Mode 64 Triggering of this input sets Normal door mode.
Set Unlocked Door Mode 65 Triggering of this input sets Unlocked door mode.
Set Conditional Unlocked
Door Mode
66
Triggering of this input sets Conditional Unlocked door mode.
Set Locked Door Mode 67 Triggering of this input sets Locked door mode.
Set LIGHT Flag ON 68 Triggering of this input turns LIGHT flag ON.
Set LIGHT Flag OFF 69 Triggering of this input turns LIGHT flag OFF.
Toggle LIGHT Flag
ON/OFF
70 Triggering of this input switches LIGHT flag to inverse condition.
Set AUX1 Flag ON 71 Triggering of this input turns AUX1 flag ON.
Set AUX1 Flag OFF 72 Triggering of this input turns AUX1 flag OFF.
Toggle AUX1 Flag ON/OFF 73 Triggering of this input switches AUX1 flag to inverse condition.
Set Disarmed Mode 78 Triggering of this input turns controller to Disarmed mode.
Set Armed Mode 79 Triggering of this input turns controller to Armed mode.
Set Card or PIN Mode 80 Triggering of this input sets Card or PIN identification mode.
Set Card only Mode 81 Triggering of this input sets Card only identification mode.
Set PIN only Mode 82 Triggering of this input sets PIN only identification mode.
Set Card and PIN Mode 83 Triggering of this input sets Card and PIN identification mode.
Note: It is not allowed to program two or more inputs to the same function.
