5 P ROGRAMMING
The PR311 controller can be programmed manually or from PC. There are two programming modes: the User
Programming Mode and the Installer Programming Mode. The User Programming Mode is dedicated to maintain
Cards and PINs programmed to a unit and for a control of the outputs. The Installer Programming Mode is
dedicated for a detailed configuration of a unit.
5.1 Memory Reset Procedure - Programming MASTER Identifier
The Memory Reset Procedure clears entire contents of the PR311 memory and restores default settings.
During this procedure the new MASTER identifier and the new controller ID number (address) can be
programmed. After Memory Reset the MASTER identifier operates also as INSATLLER identifier, so it can be
used later to enter the Installer Programming Mode. The Memory Reset consists of the following steps:
Power down the unit.
Remove all connections from CLK and DTA lines.
Make connection between CLK to DTA lines.
Restore power, the unit will generate a continuous beep.
Wait until the LED OPEN (green) starts flashing.
Disconnect CLK from DTA.
Enter one from the following sequences:
Sequence A: [Card] or
Sequence B: [New MASTER PIN][#][New MASTER Card][#] or
Sequence C: [New MASTER PIN][#][New MASTER Card][New ID address][#]
Controller generates the OK signal (two series of three beeps)
Once the previous step has been completed the unit automatically ends the Memory Reset Procedure
and enters an operating mode.
The programming sequence A programs the new MASTER card only, the controller ID number is automatically
set to ID=00. The programming sequence B programs new MASTER PIN and the new MASTER card, the
controller ID number is automatically set to ID=00. The programming sequence C programs new MASTER PIN,
new MASTER card and sets new ID number. If the Memory Reset is not accomplished successfully after power
up the controller will signal memory error (LED SYSTEM is ON and the controller generates acoustic signal in
sequence 2s sound/2s pause).
Note: Controller ID number must be in range from ID=00 to ID=99.
5.2 User Programming
In the PR311 the User Programming consist of 10 programming commands which can be accessed directly from
the either Armed or Disarmed mode. As a default each of the user programming commands requires a MASTER
identifier to be entered during programming sequence, nevertheless this obligation can be switched off for
some (or all) commands by the installer, if such occur command(s) can be accessed by every user.
When you start entering a command sequence the LED SYSTEM starts flashing and it keeps flashing until the
command is accomplished. If the controller receives no valid input (entries) from you for more than 20 sec. it
automatically leaves the command procedure and returns to operating mode it was before.
5.2.1 User Programming Commands
Legend:
[NNN]– three digits which specify the user ID number, the allowed range is from 001 to 999, always three
digits
[MASTER] – the MASTER identifier, t can be a card, a PIN or both, (depends of actual identification mode set
for a unit)
[INSTALLER] - the INSTALLER identifier, it can be a card, a PIN or both (depends of actual identification mode
set for a unit)
[PIN] – PIN code, from 3 to 6 digits followed by a [#],
[Card]– Card presented to a unit,
(SK) – controller generates two short sounds (beeps)
(OK) – controller generates three short sounds (beeps)
(Error) – controller generates one long sound (2s duration)
[01#] [INSTALLER] – Entry to the Installer Programming Mode
The unit will enter the Installer Programming Mode. Once in this mode the detailed configuration of the
controller can be carried out.
