Roger PR311 - Installer Programming Functions

PR311 v1.0 fv102 EN Rev.E.DOC 10/22/2007
16
5.3 Installer Programming
Use this mode to configure various functionalities of the PR311 controller. You can enter it from either from
Armed or Disarmed mode by following command:
[01#] [INSTALLER]
Note: No matter what is the actual Identification Mode set on the controller the [INSTALLER] can be a Card or
PIN (only one of them is required).
Once in the Installer Programming Mode the LED SYSTEN turns ON and the LED STATUS lights in green. From
this mode you have an access to various programming functions which are intended to adopt a programmed
unit for the individual installation requirements. Once the first digit of any programming command is pressed
both indicators (LED SYSTEM and LED STATUS) start to flash and continue flashing till the end of programming
command or till the moment when a programming error occur. When command is successful accomplished the
PR311 generates signal OK (three beeps) but still remains in the Installer Programming. Exit from the Installer
Programming mode can be achieved through function [00][#] or is done automatically when the controller
doesn’t have any entries through 4 minutes.
5.3.1 Installer Programming Functions
[00][#] – Exit from the Installer Programming Mode
After this command controller leaves the Installer Programming Mode and returns to either Armed or Disarmed
mode depending on the state it was before.
[40][MN] – Setting the controller’s ID number (address)
The [MN] digits specify the controller’s ID number, they may be from 00 to 99 range.
Example: [4][0][0][0] sets controller’s ID=00
Default: <ID=00> or another programmed during Memory Reset
[41][P][FW]- Setting the input type and function for IN1
The [P] digits specify a type of input which can be NO or NC, whereas the [FW] specifies the function of input.
For [FW] codes refer to section Inputs in this manual.
Program [P]=0 for NO and [P]=1 for NC.
Default: <P=1>, <FW=01>, Door Contact, NC type
Example: [4][1][0][0][1] sets IN1 as NO type and program it as Door Contact input
[42][P][FW]- Setting the input type and function for IN2
Programming rules as for function no. 41.
Default: <FW=02>, Exit Button, NO type
[43][P][FW]- Setting the input type and function for IN3
Programming rules as for function no. 41.
Default: <FW=04>, AUX, NO type
[44][P][FW]- Setting the input type and function for IN4
Programming rules as for function no. 41.
Default: <FW=00>, Input off, NO type
[45][P][FW]- Setting the input type and function for IN5
Programming rules as for function no. 41.
Default: <FW=00>, Input off, NO type
[46][OT] – Setting Time for Opening
The [OT] specifies time in seconds for which controller will activate door lock when access is granted. The [OT]
must be from 00 to 99. When [OT] is programmed to 00 the door lock is controlled in the Latch mode – each
time the access is granted the controller switches the door release device to reverse condition.
Default: <OT=04>
[47][CD] – Setting Time for Closing
The [CD] specifies amount of time allowed for door to be closed, when this time is exceed the Door Ajar alarm
will occur. Controller starts Time for Closing as soon as door became open.
Default: <CD=09>
[49][X] – Setting operation with XM-2 extension module
Enter [X]=0 if you want to disable operation with XM-2 module or enter [X]=1 to enable operation with the XM-
2 module.
Default: <X=0>,
