7 A PPENDIX
Table 8: Connection Cable Assignments
Wire Color Label Description
Red +12V Supply input plus.
Black GND Supply input minus.
Pink IN1 Input line, internally pulled up to the supply plus through a 5,6K resistor.
Blue IN2 Input line, internally pulled up to the supply plus through a 5,6K resistor.
White-Yellow IN3 Input line, internally pulled up to the supply plus through a 5,6K resistor.
Red-Blue COM
Grey-Pink NC
Violet NO
Relay output contacts, 1A/24V DC/AC rated:
COM – common
NO – normally open
NC – normally closed
Note: The relay contacts are protected with the MOV varistors, any attempt to
apply higher voltages then specified to the relay contacts will cause damage.
Yellow-Brown OUT2 transistor output, open collector type, 16V/1A, normally in high resistance, when
triggered it switches to GND (supply minus).
Green-Brown OUT3 transistor output, open collector type, 16V/1A, normally in high resistance, when
triggered it switches to GND (supply minus).
Brown A
Green-White B
RS485 communication bus:
A: Wire A
B: Wire B
White CLK Clock communication line, internally pulled up to supply plus through 5,6K
resistor.
Green DTA Data communication line, internally pulled up to supply plus through 5,6K
resistor.
Grey TMP A
Yellow TMP B
Tamper contacts, 50mA/24V rated, NC and dry:
TMP A: Wire A
TMP B: Wire B
Table 9: Technical Specification
DC Supply 10...16 VDC
Current Consumption Avg. 60 mA
Anti-sabotage Protection (Tamper) NC contact, 50mA/24V, IP67
Reading Distance Up to 12 cm for ISO cards (depends on cards)
Proximity Cards EM UNIQUE 125 kHz, ASK modulation, 64 bits (compatible with
EM4100/4102)
Communication Distance Between controller and PC (UT-2 interface): max. 1200 m
Between controller and Host (CPR32SE): max. 1200 m
Between controller and external reader: max. 150m
Between controller and XM-2 extension module:150m
Environmental Class
(according to EN 50131-1)
Class IV, Outdoor-General, temperature: -25°C- +60°C, relative
humidity: 10 to 95% (non-condensing)
Ingress Protection
IP 65
Dimensions 100 X 40 X 25 mm
Weight ~130 g
Approvals CE
