Card and PIN Mode
83
Output goes ON and remains in this condition as long as the controller
operates in Card and PIN identification mode.
Door Lock 99 Output to a door release device.
4.18 Acoustic and Optical Signals
Table 6: Acoustic signals
Signal Symbol Description
One long signal
♫
Error - unknown identifier.
Two long signals
♫ ♫
Access denied.
Three short beeps
♪♪♪
Command successfully completed (OK signal).
Two short signals
♪♪
Prompt signal, the reader is waiting for the next part of
the command to be entered. This signal is intended to
encourage the programmer to proceed with next
programming steps.
One long signal
continuously
repeated
♫ ♫ ♫ ♫ … and so on
Memory contents corrupted or MASTER card not
programmed - memory reset necessary. This signal is
accompanied by the steady lit LED SYSTEM.
Legend: ♫ - one long audible signal ♪ - one short audible signal (beep)
Table 7: LED Indications in Stand-alone Operation Mode
LED
STATUS
LED OPEN
LED
SYSTEM
Meanings
Steady
(green)
— —
Controller is disarmed.
Steady
(red)
— —
Controller is armed.
Steady
(red)
— Steady
Controller is in the Installer Programming Mode.
Flashing
(red)
— Flashing
Controller is waiting for next step during the Installer
Programming function.
— Flashing Flashing Controller is waiting for next part of the User Command.
— — Flashing Controller is waiting for an identifier.
— Steady —
The door lock is activated; this LED remains ON as long as the
door lock is energized.
— — Steady
The memory contents corrupted or MASTER identifier not
programmed. This situation is accompanied by acoustic signal
repeated in sequence: sound 2s/pause 2s
Blinking Blinking Steady
The controller is being programmed from PC, the LED STATUS and
OPEN are blinking along with data send/received by a device.
