4.17 Outputs
The PR311 provides five logical outputs. Three of them (called OUT1, OUT2 and OUT3) are located on the
controller’s electronic module while two others are located on the optional XM-2 extension module. Each output
can be configured to one of the following output functions:
Table 5: Output lines functions
Function Code Description
Disarmed Mode
00
The output line switches to ON and remains so for as long as the
controller is Armed. The output goes OFF when the controller switches
to the Disarmed mode.
Prealarm 01
Door Ajar 02
Prealarm +
Door Ajar
03
Forced Entry 04
Prealarm +
Forced Entry
05
Door Ajar +
Forced Entry
06
Prealarm +
Door Ajar +
Forced Entry
07
The output is dedicated to indicate alarm situation which occurred on
the controller. Depending on programmed code (01..07) the output can
signals one or more type of alarms. The only one alarm with highest
priority is indicated on the output. Each alarm is signaled through
different modulation of an output line.
Access Granted
09
Output turns ON each time the controller grants access and remains in
this state until the door contact indicates that the door became closed
or the lock activation time has passed.
Access Denied 11 Output is activated for two seconds each time the access is denied.
Remote Reader
14
Each time a successful identification occur on the remote reader
connected to the controller this output turns ON and remains in this
state till the nearest user identification on a main controller. Typically,
this function is used to control a direction of a rotary gate.
Door Bell
15
Output turns ON when the controller recognizes a Door Bell event,
which can be caused by a function key press or from input line.
Normal Door Mode
18
Output goes ON and remains in this condition as long as the controller
operates in Normal door mode.
Unlocked Door Mode
19
Output goes ON and remains in this condition as long as the controller
operates in Unlocked door mode.
Conditional Unlocked Door
Mode
20
Output goes ON and remains in this condition as long as the controller
operates in Conditional Unlocked door mode.
Locked Door Mode
21
Output goes ON and remains in this condition as long as the controller
operates in Locked door mode.
Pulse on Disarming
25
Output generates one low level pulse two seconds long whenever the
controller switches to Disarmed mode.
Pulse on Arming
26
Output generates one low level pulse two seconds long whenever the
controller switches to Armed mode.
LIGHT Flag
64
Output follows the condition of the LIGHT flag i.e. when the flag is ON
the output is ON, when the flag is OFF output is OFF.
TAMPER Flag
65
Output follows the condition of the TAMPER flag i.e. When the flag is ON
the output is ON, when the flag is OFF the output is OFF.
AUX1 Flag
66
Output follows the condition of the AUX1 flag i.e. when the flag is ON
the output is ON, when the flag is OFF the output is OFF.
DURESS Flag
69
Output follows the condition of the DURESS flag i.e. when the flag is ON
the output is ON, when the flag is OFF output is OFF.
TROUBLE Flag
70
Output follows the condition of the TROUBLE flag i.e. when the flag is
ON the output is ON, when the flag is OFF output is OFF
Card or PIN Mode
80
Output goes ON and remains in this condition as long as the controller
operates in Card or PIN identification mode.
Card only Mode
81
Output goes ON and remains in this condition as long as the controller
operates in Card only identification mode.
PIN only Mode
82
Output goes ON and remains in this condition as long as the controller
operates in PIN only identification mode.
