Instrument Tour
R&S
®
RTP
24Getting Started 1337.9946.02 ─ 05
1 = AC power supply connector and main power switch
2 = USB device connector, type B
3 = USB connectors, type A
4 = LAN connector
5 = DVI-D connector for external monitor
6 = DisplayPort connector
7 = GPIB connector
8 = Exchangeable solid state disk (SSD, option R&S RTP-B18)
9 = Aux Out connector
10 = External trigger output
11 = Ref In, Ref Out: reference input, and output of the OCXO reference signal
12 = Digital data interface (DDI, optional)
13 = Option slot
14 = Kensington lock slot to secure the instrument against theft
AC power supply connector and main power switch
Connection to the AC power line. The R&S RTP can be used with different AC
power voltages and adapts itself automatically to it. The nominal voltage and fre-
quency ranges are displayed on the rear panel and quoted in the data sheet.
If grounding is not ensured by the mains system, ground the oscilloscope using
the protective earth conductor on the front panel and an appropriate cable.
The AC main power switch also interrupts the power supply of the OCXO.
When you power up the instrument, be sure to comply with the warm-up phase
specified in the data sheet before you start measurements.
USB Device
USB 3.0 interface of type B (device USB), to be used for remote control of the
instrument.
USB
Four USB type A connectors. Two connectors comply with standard USB 3.0, and
the other two with standard USB 2.0. They are used to connect devices like key-
board, mouse, printer, and flash drive to store and reload instrument settings and
measurement data.
Note: Electromagnetic interference (EMI) can affect the measurement results. To
avoid any impact, do not use USB connecting cables exceeding 1 m.
LAN
8-pin RJ-45 connector used to connect the instrument to a Local Area Network
(LAN). It supports up to 1000 Mbit/s (10/100/1000BASE-T Ethernet).
Rear Panel
