DDI 40G
Optional digital data interface for input and output of digital data.
Option slot
Slot to install one of the options R&S RTP-B1 (MSO) or R&S RTP-B1E (for
R&S RT-ZVC) if both slots at the front panel are used for other options. To install
the option, the R&S RTP-B21 slot adapter is required. The options and their con-
nectors are briefly described in Chapter 4.1, "Front Panel", on page 20.
4.3 Keys and Controls
4.3.1 Power Key
The [Power] key is located on the lower left corner of the front panel. It starts up
and shuts down the instrument's software.
The light of the key shows the instrument state:
●
Orange: standby, the main power switch is on, the software is shut down.
●
Green: The instrument is ready for operation.
4.3.2 Setup Controls
Setup keys set the instrument to a defined state, change basic settings, and pro-
vide print and help functions. The intensity rotary knob adjusts the display con-
trast for several display elements.
[Autoset]
The instrument analyzes the enabled channel signals, and adjusts appropriate
horizontal, vertical, and trigger settings to display stable waveforms.
[Preset]
Resets the instrument to a default state. All measurements, mask tests, zoom,
and most individual settings are deleted, and all channels except for channel 1
are disabled. You can define preset configurations and save them to a file. The
[Preset] key can be configured to set either factory defaults or a user-defined pre-
set configuration.
