Roland Camm-1 GR2-640 User Manual

To purchase consumable items, visit the Roland DG Corporation website (http://www.rolanddg.com/) or
contact your authorized Roland DG Corporation dealer.
Blade
In the cases below, the blade has reached the end of its service life. Replace with new items.
• The tip of the blade is broken.
• Uncut areas remain even though the blade force has been increased to 50 to 60 gf.
• The cutting edge is dull.
• The material starts to curl up from the carrier paper when cutting detailed areas or corners.
• The tip of the blade has worn down due to long-term use or cutting hard material.
Blade holder
After the tip of the blade has been adjusted, the cap of the blade holder rubs against the material
when cutting, causing the end of the cap to gradually wear away. As the cap becomes increasingly
worn it becomes impossible to adjust the tip of the blade correctly, and clean cutting is no longer pos-
sible. When this happens, replace the blade holder with a new one.
Blade protector
In the cases below, replace the blade protector.
• The surface of the blade protector is deformed due to scratching or similar damage.
• The blade protector has deteriorated to the point it is falling apart.
Replacing Consumable Parts
Cleaning and Replacing Consumable Parts 137

Roland Camm-1 GR2-640 Specifications

General

Model	Roland Camm-1 GR2-640
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Maximum Cutting Speed	1, 485 mm/s
Cutting Force	600 gf
Interface	USB 2.0, Ethernet
Maximum Cutting Area	1, 651 (W) x 50, 000 (L) mm
Blade Force	600 gf
Software Resolution	0.025 mm/step
Distance Accuracy	±0.1% of distance traveled, or ±0.1 mm
Repeatability	±0.1 mm
Alignment Accuracy for Print & Cut	±0.1 mm (0.0004 in) or less
Operating Temperature	5 to 40°C
Operating Humidity	35 to 80 % RH (no condensation)
Dimensions (with stand)	73.8 in. (W) x 28.5 in. (D) x 44.5 in. (H) (1, 875 mm (W) x 723 mm (D) x 1, 130 mm (H))
